Product Infromation: electronic control

via soft touch button control

for installation in a kitchen cabinet

70 cm wide

brushed steel

features

soft touch button control

with electronic display

3 power levels

intensive setting

automatic intensive revert (6mins)

rim ventilation

2 x 1w led

light colour: warm white

2 removable metal grease filter cassettes

filter cover stainless steel

removable metal grease filters

performance/technical information

suitable for ducted or recirculating operation

extraction rate according to en 61591 ø 15 cm:

max. normal use 630 m3/h

intensive 730 m3/h

extraction rate exhaust air according to en 61591:

max. normal use 630 m3/h

intensive 730 m3/h

power rating: 277 w

noise level according to en 60704-3 and en 60704-2-13 exhaust air:

max. normal use: 66 db(a) re 1 pw

(52 db(a) re 20 µpa sound pressure)

intensive: 69 db(a) re 1 pw

(55 db(a) re 20 µpa sound pressure)

noise max. normal level: 66 db*

average energy consumption: 105.7 kwh/year*

energy efficiency class: c*

blower efficiency class: c*

lighting efficiency class: a*

grease filtering efficiency class: d*

dimensions exhaust air (hxwxd):

418-418 x 700 x 300 mm

dimensions recirculating (hxwxd):

418-418 x 700 x 300 mm

diameter pipe Ø 150 mm (Ø 120 mm enclosed)

light intensity: 244 lux

colour temperature: 4000 k

optional accessories

for recirculated extraction

charcoal filter (accessory) needed
