60cm

3 speed

push buttons

led lights

high extraction rate

push button control operation

3 power levels

2 x 3w led

colour temperature: 2700 k

2 metal grease filter cassettes

for installation between cupboards

mechanical controls

suitable for:

ducted extraction

recirculation (filter sold separately)

extraction rate according to en 61591 max. 350 m³/h

noise max. normal level: 70 db*

noise level according to en 60704-3

and en 60704-2-13 at max. normal use

exhaust air: 70 db(a) re 1 pw (56 db(a) re 20 µpa sound pressure)

light intensity: 188 lux

colour temperature: 2700 k

electrical cable length 1.5 m

diameter pipe Ø 150 mm (Ø 120 mm enclosed)

dimensions exhaust air (hxwxd):

402-402 x 599 x 271 mm

dimensions recirculating (hxwxd):

402-402 x 599 x 271 mm

energy efficiency class: b

(at a range of energy efficiency classes from a++ to e)*

blower efficiency class: b*

lighting efficiency class: a*

grease filtering efficiency class: c*

average energy consumption: 68.4 kwh/year

dimensions (hxwxd):

402 x 599 x 271mm optional extra (purchased separately):

recirculating filter: z51ima0x0
